Based on the proven technology of the Xantrex™ DR Series of which more than 80,000 were sold, the Xantrex™ Trace Series Inverter/Charger is an economical modified sine wave inverter designed to provide dependable power for home or business. The Trace series is an economical and popular off-grid power solution. Available in 12 and 24 volt models, it offers high surge capacity to run most household and business appliances. Its built-in, fully automatic, three-stage battery charger is designed to bring maximum charge to batteries, while using minimum generator run time and fuel.
|
Specification / Model |
TR1512 |
TR2412 |
TR1524 |
TR2424 |
TR3624 |
|
Continuous Power (@ 25°C) |
|
|
|
|
|
|
AC Current at Max. Charge Rate
|
11.20 |
15.81 |
10.20 |
19.68 |
19.53 |
|
Rated Output Current AC Amps |
12.5 |
20 |
12.5 |
20 |
30 |
|
Typical Efficiency |
90% |
92% |
92% |
93% |
94% |
|
AC Output Voltage (rms) |
120 Vac |
||||
|
Max. Output Overcurrent Protection |
30 amps AC |
45 amps AC |
|||
|
Surge Capability/Max. Output and Duration: Overload 10 sec Rating |
|
|
|
|
|
|
Short Circuit 10 sec Rating
|
50±5 Apk |
80±8 Apk |
50±5 Apk |
80±8 Apk |
120±12 Apk |
|
DC Current at Rated Power
|
157 |
252 |
76 |
120 |
186 |
|
DC Input Voltage (nominal) |
12.6 Vdc |
25.2 Vdc |
|||
|
DC Input Voltage Range |
11.0—15.0 V |
22.0—30.0 V |
|||
|
DC Charger Rate Amps |
10 to 70 |
14 to 100 |
5 to 35 |
10 to 70 |
10 to 70 |
|
Power Factor while Charging |
0.88 |
0.89 |
0.88 |
0.92 |
0.93 |
|
Tare Loss (Watts) |
26 |
25 |
24 |
||
|
AC Nominal Input |
120 Vac |
||||
|
Maximum AC Input |
140 Vrms |
||||
|
Input Low Transfer Voltage (wide/narrow) |
65/95 Vac |
||||
|
Frequency: (± 0.04% Crystal controlled) |
60 Hz |
||||
|
Narrow Setting (Charge & Pass - through) |
55—64 Hz |
||||
|
Wide Setting (Charge) |
55—68 Hz |
||||
|
Wide Setting (Pass-through) |
41—68 Hz |
||||
|
Maximum AC Input Current |
50 Aac |
||||
|
Pass-through |
30 Aac |
||||
|
Charging |
20 Aac |
||||
|
Nominal Input Current |
40 Aac |
||||
|
Pass-through |
28 Aac |
||||
|
Charging |
12 Aac |
||||
|
Voltage Regulation (max.) |
104—127 Vac |
||||
|
Voltage Regulation (Typical) |
108—125 Vac |
||||
|
Waveform |
modified sine wave |
||||
|
Load Power Factor (allowed) |
0.8 to 1.0 (leading or lagging) |
||||
|
Adjustable Load Sensing Range |
5 watts minimum to 240 watts maximum |
||||
|
Force Air Cooling |
Variable speed fan |
||||
|
Automatic Transfer Relay
|
30 amps maximum (non-continuous) |
||||
|
Stacking |
|
Two units can be connected to produce 120/240 Vac split phase power, stacking cable included |
|||
Features
Better
thermal performance allows full output power to 50°C (122°F) without de-rating
Pin-sized vent holes prevent pests from getting inside and building nests
sophisticated multi-stage battery charging algorithm
Charger turns off once batteries are fully charged, reducing energy bills.
Battery life is prolonged because batteries are notcontinually held at float voltage.
Power factor corrected (PFC) charging
Electrical draw is reduced by up to 30% less AC input current, while delivering the same DC charging current.
Reduced electrical noise and interference with TV’s and radios
Trace Series inverter-chargers are FCC Class B Compliant with necessary EMI filtering components.
Complete system solution with modular components
Trace Series inverter-chargers are bundled with a plug-in battery temperature sensor, which automatically fine tunes the charging process in relation to temperature.
Options
TR-Remote On/Off Switch – includes LED status indicator (P/N: 989-1060)
TR-Conduit Box – connects to the DC side of the inverter and accepts ?", 1" or 2" conduit (P/N: 989-1050)
