LG The Apex of Solar Generation


The LG NeON R is LGs premier module armed with the highest and most efficient energy generation technology that LG has ever produced. LG NeON R not only generates the most energy from LGs lineup but is also the most stable in all environmental conditions.

Electrical Properties

The first chart below shows power at Standard Test Condition (STC) which is at cell temperature of 25 C
The chart that follows shows what few manufacturers talk about and most avoid.  ALL Solar cells at Normal Operating Cell Temperature
produce about 20% less power

Model   LG360S2W-A5 LG355S2W-A5
Maximum Power (Pmax) [W] 360 355
MPP Voltage (Vmpp) [V] 37.7 37.4
MPP Current (Impp) [A] 9.56 9.50
Open Circuit Voltage (Voc) [V] 46.6 46.4
Short Circuit Current (Isc) [A] 10.12 10.07
Module Efficiency [%] 17.4 17.1
Operating Temperature [C] -40 ~ +90
Maximum System Voltage [V] 1,000(IEC), 1,500(UL)
Maximum Series Fuse Rating [A] 20
Power Tolerance [%] 0 ~ +3
Model   LG360S2W-A5 LG355S2W-A5
Maximum Power (Pmax) [W] 264 260
MPP Voltage (Vmpp) [V] 34.6 34.3
MPP Current (Impp) [A] 7.63 7.58
Open Circuit Voltage (Voc) [V] 43.2 43.0
Short Circuit Current (Isc) [A] 8.14 8.10
* NOCT (Nominal Operating Cell Temperature): Irradiance 800 W/m2, ambient temperature 20 C,

Mechanical Properties

Cells 6 x 12
Cell Vendor LG
Cell Type Monocrystalline / N-type
Cell Dimensions 161.7 x 161.7 mm / 6 inches
# of Busbar 12 (Multi Wire Busbar)
Dimensions (L x W x H) 2,024 x 1,024 x 40 mm
  79.69 x 40.31 x 1.57 in
Front Load 5,400 Pa / 113 psf*
Rear Load 4,300 Pa / 90 psf*
Weight 21.7 kg / 47.84 lb
Connector Type MC4 (MC)
Junction Box IP68 with 3 Bypass Diodes
Cables 1,200 mm x 2 ea / 47.24 in x 2 ea
Glass High Transmission Tempered Glass
Frame Anodized Aluminium


Certifications and Warranty

Certifications IEC 61215, IEC 61730-1/-2
UL 1703
IEC 61701 (Salt mist corrosion test)
IEC 62716 (Ammonia corrosion test)
ISO 9001
Module Fire Performance Type 1 (UL 1703)
Fire Rating Class C (ULC/ORD C 1703, IEC 61730)
Product Warranty 25 Years
Output Warranty of Pmax Linear Warranty*


Specifications subject to change without notice.
