Deka Solar Battery Series

The Deka Solar series of batteries is designed to offer reliable, maintenance-free back-up power for renewable energy applications where frequent deep cycles are required and minimum maintenance is desirable. East Penn offers flooded, gel valve-regulated, and absorbed valve-regulated technologies to fit all of your solar applications.

Deka Solar Battery Series

Cell Type

Volts

Style



Dimensions

8GGCZ

6V

Sealed Gel

180 Ah

10.25" x 7.13" x 10.8

DC27

12V

Flooded

90 Ah

12.50" x 6.75" x 9.88"

908D

12V

Flooded

190 Ah

20.75" x 11.00" x 10.00"

8GUI

12V

Sealed Gel

31 Ah

7.75" x 5.13" x 7.25"

8G8D

12V

Sealed Gel

225 Ah

20.75" x 11.0" x 10.0

8G22NF

12V

Sealed Gel

48 Ah

9.40" x 5.50" x 9.25

8L16

6V

Flooded

370 Ah

11.75" x 7.00" x 16.50"

8G31

12V

Sealed Gel

98 Ah

12.90" x 6.75" x 9.40"

8G27

12V

Sealed Gel

86 Ah

12.75" x 6.75" x 9.87"

8G24

12V

Sealed Gel

70 Ah

10.88" x 6.75" x 9.88"

8G4D

12V

Sealed Gel

180 Ah

20.75" x 8.50" x 10.0















Deka Solar Flooded System

Jar and Cove:             Molded high impact polypropylene.

Separators:                 Microporous polyethylene material

Retainers:                   Vertically and horizontally wrapped glass mat, folded perforated envelope,

molded plastic bottom shield

Positive and Negative Plate:   Antimony flat plate

Specific Gravity (fully charged):   1.250 @ 25C (77F).

Self discharge:            1% per week

Cycle life:                   1500 cycles @ 80% DOD, 4000 cycles @ 20% DOD

                                 [Number of cycles based on 6-hr. rate @ 25C (77F)]

Features

High capacity flat plate cells Long life: 12 to 14 years in shallow cycle service

Extended watering interval - up to six months because of a large reservoir for electrolyte

Thermally sealed cover to container Long-lasting epoxy coated steel trays

Special mounting brackets on tray for enhanced stability Custom design modules

Discharge Ratings for  Deka Solar Flooded System Batteries

Cell Type

AHr @20hr

AHr @100 hr

M100-33

1896

2326

M100-31

1779

2182

M100-29

1659

2035

M85-33

1612

1978

M100-27

1541

1891

M85-31

1512

1854

M100-25

1423

1746

M75-33

1422

1746

M85-29

1411

1731

M75-31

1333

1637

M85-27

1310

1607

M100-23

1304

1600

M75-29

1244

1528

M85-25

1209

1483

M100-21

1186

1455

M75-27

1155

1419

M85-23

1109

1360

M75-25

1067

1310

M100-19

1067

1309

M85-21

1008

1236

M75-23

978

1200

M100-17

949

1164

M85-19

907

1113

M75-21

889

1091

M100-15

830

1018

M85-17

806

989

M75-19

800

982

M100-13

712

873

M75-17

711

873

M85-15

705

865

M75-15

622

764

M85-13

605

742

M100-11

592

727

M75-13

533

655

M85-11

504

618

M100-9

474

582

M75-11

444

546

M85-9

403

494

M75-9

356

437

M100-7

355

436

M85-7

302

371

M75-7

267

327

M100-5

237

291

M85-5

202

247

M75-5

178

218
